CNC Laser Sheet Metal fiber Cutting Machine 6090 500W 1KW with Cypcut Control System

Brand Name: MORN

Condition: New

Model Number: MT-L6090F

CNC or Not: CNC

Product name: Fiber laser cutting machine

Power: 300W(500W/750W/100W/1500W optional)

Working area: 600*900mm

Laser type: Raycus (IPG / Nlight) Fiber laser source is optional

Motor: Japan servo driver and motors

Application: Metal cutting

Cooling chiller: CW6000

Accuracy: 0.002mm

Cooling mode: Water cooling

Voltage: 380V/220V

CNC Laser Sheet Metal fiber Cutting Machine 6090 500W 1KW with Cypcut Control System

NOTES: This price is FOB price. Please contact us to confirm the shipping cost before order.



1. Double gear rack system and imported servo driver system, ensure high accuracy and high working efficiency during high speed cutting.



2. Fiber laser cutting machine equipped with laser power 300W, 500W, 1000W, 2000W, etc. Low operating and maintenance costs. Achieve long-term return on investment and revenue maximization.



3. Enclosure design conforms to CE standard for reliable and safe processing.



4. Aiming at high speed cutting, strengthened welded machine body after 2 times of aging process, ensuring long-term accuracy and stability of performance.



5. Dual-pressure gas control system of 3 gas sources ( high pressure air, nitrogen, oxygen ) meets the processing requirement of all kinds of metals. Easy operation and low cost.



Model                                          MT-L6090F
Laser power 300 W Working  Area 600*900 mm Z-axis travel 100 mm / 4" Single-mode continuous fiber laser 1.07 um wavelength Laser wattage 300 / 500 / 750 / 1000 W optional Beam quality <0.373 mrad Positioning accuracy <= 0.03 mm/m Max. no load speed 60 m/min / 196 ft/min Fiber source Raycus (NLIGHT/IPG optional) Air-assist Oxygen or Nitrogen Resolution Ratio 0.1 mm Marking Content Text, pattern, date, bar code, etc Operation System Microsoft Windows XP or Windows 2000 Control Software EZCAD Control Software Graphic Format Supported BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. Warranty 1.2 KW Operation Temperature 5°C-40°C Control System Cypone full-closed loop servo control Dimensions(L*W*H) 292 x 171 x 221 cm  1500kg Driving Mode  Gear rack driving Water cooling of supply and laser head CW6000 industrial refrigerated water chiller





Sheet metal processing, Die-cutting, Electronic, Electrical appliance, Aviation, Mechanical, Elevator, Cars, Steamer, Cutting tool, Subway accessories, Petroleum machinery, Food machinery, Craft gits, Tools processing, Decoration, Advertisement, Metal external processing and other manufactures.



1. 3 year for whole machine, 2 year for laser generator

2. Lifelong technical support online or by email

3. 18 hours online service to help you use our machine well

4. Offer oversea service for training,installing,operating if necessary

5. Offer training at our factory for free(you could visit us and learn)

6. CE and FDA certificate, the machines are produced according to standard.

Before Delivery:.

Check and test machine  at least 10 times to make sure all right.

18-year manufacturing experience on laser machine equipment; 3-year warranty; 7*24h professional after sales online service; Overseas warehouse available in the US and the UK; Technical engineers available for overseas service.



1) May we know the speed of your Fiber Laser Cutting Machine as per on our demand basis?

  We use Japan Servo motor and driver with big strength, so the max moving speed can reach 100m/min, max cutting speed can reach 40m/min. And the speed can reach 1.5-2m/min if you cut 4.5-5mm stainless steel.



2) About accuracy, we have observed that after some time "Machine accuracy can increase gradually" and after long time, the difference reach to its maximum level. How about your machine?

The frame of the machine is annealed, it can support shock resistance(the machine will deform if without annealing ). So the accuracy of the machine can keep its original accuracy for 4-5years. The weight of the machine can reach 4.5t-5.0t. It also can let the machine have higher accuracy and higher stability.



 3) Scan Cutting Option is available? (Means short distance cutting without lifting head?)

Yes, this machine can short distance cutting without lifting head. It can save about 2s-3s.



4) Can power be controlled with two layers (one cut another mark) in which cut and mark on one metal part?

Yes, it can cut and mark through adjusting the power.



5) Automatic search edge function is available? In which machine can auto detect or auto detect cutting?

Yes, this type machine has automatic search edge function.



6) Power off cutting memory function available? In which if power off sudden then start from the break point.

Yes, it has breakpoint memory function. So it can continue cutting if the power off suddenly.



7) To control cabinet temperature through Air condition option available?

There are two sets system to control temperature.
Air cooling: for controlling the temperature of driver, laser generator, electrical components, etc .Water cooling: for controlling the temperature of laser generator and laser head.



1.If you choose seller shipping method, please email us your port name to double check if it can be reached and delivery time. Please reconfirm the shipment information: consignee/contact person, detailed address, telephone number.

For Russia and Ukraine, we can ship machine to your city by land transportation. Please contact us to confirm the shipping cost and customs tax.

2. When payment and shipping information are confirmed, shipping will be made within 7 working days.

3. It\'s CIF trade term (insurance included). The buyer should pay surcharge of port, including handling charges, custom clearance cost and import taxes. EXW and FOB terms are also acceptable. We ship goods by sea to your seaport (you need to find broker to help you clear customs).

4. On arriving at the destination port, the machine should be picked up soon. Or the buyer should pay the relevant demurrage charges.

5. If want other courier like DHL, TNT, UPS, FedEx or EMS, please also provide us with your city name and post code, so we can check the delivery detail and cost.

6. Please check all goods carefully and report to us within one week if there are any parts loss or machine problems (photo evidence needed). The machine is specially customized product with big size, so we do not accept return with pretty high return cost. But we are confident in our products quality. And lifetime tech support and free spare parts (Consumable parts not included) during warranty will be offered for each buyer.

7. If we are not on line, please leave us messages on Aliexpress about any questions on our product or your order, then we will reply you within 24 hours.
