Variable Frequency Drive VFD 2 2kw Inverter 1 5kw Spindle For Cnc Machine
Variable Frequency Drive VFD 2.2kw inverter 1.5kw spindle for cnc machine
Variable Frequency Drive VFD 2.2kw inverter 1.5kw spindle for cnc machine
Parameters：
| Name | Variable-frequency Drive |
| Model | HY |
| Power | 2.2KW/1.5KW |
| Input voltage | 110V/220VAC/50Hz |
| Maximum output frequency | 0-400Hz |
| Output voltage | 3 phase0-220VAC |
| Weight | 2.0kg |
| Product size | 168*124*161mm |
| Package size | 210*170*210mm |
| Appendix | Manual (including warranty card) |
Features:
Uses the Japanese MITSUBISHI microprocessor
Voltage space vector SVPWM control
Adjustable V/F line
With automatic voltage output
Optional torque elevation
Unique dead time compensation function
Ensure low frequency high torque output
As many as 155 main menu parameters can be set up
6 function programmable input terminal
The built-in PLC can realize 16 speed control
A variety of external analog voltage input current
Wide voltage working, able to function normally in +20%
Perfect fault protection and short circuit starting protection function
16KHz carrier frequency adjustable, completely mute operation
The built-in RS485 interface, the international standard MODBUS protocol
Package included:
1 X Main Unit
Note:
The link is 220V , If you need 110V ,Please Leave a message in the order; thank you!
