Hot Sale Good Quality Cautery On Wood Cnc Stone Carving Machine 1325 With CE ISO
Hot sale Good quality cautery on wood / cnc stone carving machine 1325 with CE ISO
Product Application :
Applicable industries of computer controlled wood router:
♥Wooden door and furniture decoration industry: Solid wood door, compound door, cupboard
door, large area plank plane carving, wood carve designs, board type furniture engraving, archaize
annatto furniture engraving, solid wood art mural engraving and so on.
♥Wooden crafts processing: Clock frame, picture frame, calligraphy plaque, electrical counter face,
sports equipment, thin aluminum board cutting and engraving.
♥Electronic product industry: Circuit board, insulation materials, the LED display, home appliance
(color TV sets, washing machines, refrigerators) shell or model engraving and cutting;
♥Instrument industry: Engraving instruments 3D surface, Appearance cutting, such as cello, violin
panel and head; guitar, erhu 3D surface engraving and cutting.
♥EVA processing industry: EVA packing materials lined engraving and cutting for tool equipment,
medical equipment, electronic products, glass vessel.
♥Other industries: The building model, the block, aviation block, propellers, car foam mold.
Main Features :
1 Thicker square tube bed makes the operation more stable and accuracy.
2 Our machines adopt the vacuum or T-slot dual-use table, you can use the clips to fix the small-scale materials, which can save the vacuum pump electricity, and you can adopt the vacuum adsorption to fix large-scale material.so the processing is convenient, simple and efficient.
3 High quality Taiwan imported Linear guide has much longer life 10 times of life-time than round guide; It is stable and hard to distort.
4 3KW top brand water cooling spindlehas much powerful strength; So for processing your softmetal it will have higher efficiency.It will have a better effect .
5 the DSP control system is a very popular control system with high quality. All of our big machines use the DSP control system.
6 Double motor for Y axis make the cnc machine work with more strength ;
7. 4 th rotary can manufacture cylinder samples .
Details of wood cnc milling machine
| Working Area | 1300*2500*200mm |
| Traveling Positioning Accuracy | ±0.03/300mm |
| Repositioning Accuracy | ±0.03mm |
| Table | vacuum or T-slot Table |
| Frame | Welded Structure |
| X, Y axis | helical rack 1.25M, Hiwin 20# Rail Linear Bearing |
| Z axis | Hiwin Rail 20# Linear Bearing & Taiwan TBI Ball Screw |
| Max. Power Consumption | (Without Spindle) 2.5kw~3Kw |
| Max. Rapid Travel Rate | 33000mm/min |
| Max. Working Speed | 25000mm/min |
| Spindle Power | 5.5KW air cooling spindle |
| Spindle Speed | 0-24000RPM |
| Drive Motors | stepper or servo motor |
| Working Voltage | AC380V/50/60Hz,3PH (Option: 220V) |
| Command Language | G Code |
| Operating System | Mach3 PC Software with USB port |
| Computer Interface | USB |
| Flash Memory | 128M(U Disk) |
| Collet | ER25 |
| X,Y Resolution | <0.01mm |
| Software Compatibility | Type3/UcancameV9/Artcam Software |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
CNC woodworking router machine of AKM1325D detail parts photos :
# Working area:1300*2500*200 mm
# 350V 50/60Hz, 3 phase
# China high quality Changsheng 5.5Kw Air cooling spindle, speed is 0-24000rmp, Made in China
# X/Yaxis gear-wheel transmission, Z axis Taiwan TBI ball screw transmission
# Taiwan square 20 rails, High quality
# Tool sensor
# Two sides with limited switch
# Water tank (use for cooling metal or stone )
# Mach3 controller system working on the computer, USB connection
# Stepper motors and Leadshine drivers
# Fuling inverter
Samples of cnc router machine engraving and cutting machine :
Q: Are you not sure if this machine suitable for your work?
A: Don\'t worry, just tell me your working materials, max working area and cutting
thickness, then I will recommend you the most suitable machine for you. If you have
any other special requirements, just tell me, we will try our best to meet your needs.
Q: Are you worrying about the transportation of your machine?
A: Don\'t worry, we usually transport your machine by sea, so if it is convenient to you, pls tell me your nearest shipping port, then I can confirm the shipping freight for you. Pls notice, not all the port are free.
1.1.5 years quality guaranty, the machine with main parts(excluding the consumables)
shall be changed free of charge if there is any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an agency price when you need replacement.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery
7.Our staff can be sent to your company to install or adjust if necessary.
Our technician supply service go to abroad many different country and user\'s feed back :
Many customers visit our factory and made cooperations :
